Waveguide Junction Circulators
Theory and Practice
Joseph Helszajn (Author)
9780471982524, Wiley
Hardback, published 24 September 1998
560 pages
24.7 x 17.2 x 3.6 cm, 1.077 kg
Dieses ma?gebliche Nachschlagewerk zu Experimenten und Messungen auf dem Gebiet der Mikrowellenschaltkreise deckt alle theoretischen und praktischen Aspekte des Designs von Wellenleitern und anderen Bauelementen der Mikrowellentechnik ab. Angewendet werden derartige Bauelemente beispielsweise in Mobiltelefonen, Satelliten, Navigationssystemen und Radaren. (8/98)
Preface ix 1 Architecture of Symmetrical Waveguide Junction Circulators 1 2 Scattering Matrix of m-Port Circulator 23 3 Eigenvalue Adjustment pf 3-Port Circulator 39 4 Impedance Matrix of Junction Circulator 57 5 The Post Gyromagnetic Resonator 77 6 Okada Resonator 89 7 Isotropic, Anisotropic and Gyromagnetic Circular Waveguides 109 8 Isotropic, Anisotropic Open Circular Wavelengths 139 9 The Dialectric Cavity Resonator 155 10 The Gyromagnetic Cavity Resonator 179 11 Impedance in Rectangular, Ridge and Radial Waveguides 199 12 Junction Circular Using Post Resonators 229 13 Complex Gyrator Circuit of a Waveguide Junction Circulator using an Okada Resonator 255 14 Degree-1 and 2 Okada Circulators 279 15 An Evanescent Mode Okada Junction Circulator 297 16 Complex Gyrator Circuit of an H-Plane Junction Circulator using an Okada Resonator 311 17 Complex Gyrator Circuit of an Evanescent-Mode E-Plane Junction Circulator using H-Plane Turnstile Resonators 339 18 Waveguide Circulators using Triangular and Prism Resonators 359 19 Synthesis of Quarter-Wave Coupled Junction Circulators with Degrees 1 and 2 Complex Gyrator Circuits 379 20 The 4-Port Single Junction Waveguide Circulator 399 21 Microwave Switching using Junction Circulators 431 22 Insertion Loss of Waveguide Circulators 431 23 Synthesis of Stepped Impedance Transducers 445 24 Experimental Evaluation of Junction Circulators 471 25 Circulator Specifications 489 26 Gyromagnetic Effect in Magnetic Insulator 511 Index 537
Subject Areas: Electronics & communications engineering [TJ]
