Power Electronic System Design
Linking Differential Equations, Linear Algebra, and Implicit Functions

Helps model the power electronics elements of mathematical design forms, leading to clearly visible and comprehensible solutions, including component selection and performance estimation

Keng C. Wu (Author)

9780323885423, Elsevier Science

Paperback / softback, published 23 June 2021

405 pages, Approx. 300 illustrations
22.9 x 15.1 x 2.6 cm, 0.66 kg

Power Processing Circuits Design seamlessly infuses important mathematical models and approaches into the optimization of power processing circuits and linear systems. The work unites a constellation of challenging mathematical topics centered on differential equations, linear algebra and implicit functions, with multiple perspectives from electrical, mathematical and physical viewpoints, including power handling components, power filtering and power regulation. Power applications covered encompass first order RC and RL, second order RLC circuits with periodic drives, constant current source, close-loop feedback practices, control loop types, linear regulator, switch-mode regulator and rotation control.

1. Capacitor and Inductor2. First Order Circuits3. Current Source4. Second Order5. Gain Blocks6. Feedback Approaches7. Control Practices8. Linear Regulator9. Switch-mode DC/DC converters10. AC drives, rectification and inductive loads11. Rotation, Three Phase Synthesis, and Space Vector Concepts

Subject Areas: Electric motors [THRM]
