Nonlinear Electronics 2
Flip-Flops, ADC, DAC and PLL

Presents interface circuits, analog-to-digital conversion, analog-to-analog conversion, and phase-locked loop

Brahim Haraoubia (Author)

9781785483011, Elsevier Science

Hardback, published 14 August 2019

326 pages
22.9 x 15.1 x 2.4 cm, 0.64 kg

Nonlinear Electronics 2: Flip-Flops, ADC, DAC and PLL deals with the appearance of nonlinear electronic circuits and their behavior. The book covers a number of circuits that interface between analog and digital electronics, such as astable, monostable, biostable, Schmitt trigger, analog-to-digital conversion and digital-to-analog conversion. In addition, the book deals with all aspects of these circuits, starting from discrete component and gradually going to the integrated circuit.

1. Nonlinear dipoles
2. Low frequency oscillators
3. High frequency oscillators
4. The non-linear oscillator-device
5. Switched circuits
6. The astable multivibrators
7. Monostable and bistable flip-flops
8. Schmitt's rocker
9. Analog and digital and digital analog conversion

Subject Areas: Electrical engineering [THR]
