Noncircular Gears
Design and Generation

Examines the theory of the design and generation of noncircular gears that are applied in automatic machines and instruments.

Faydor L. Litvin (Author), Alfonso Fuentes-Aznar (Author), Ignacio Gonzalez-Perez (Author), Kenichi Hayasaka (Author)

9780521761703, Cambridge University Press

Hardback, published 14 September 2009

214 pages, 144 b/w illus. 6 tables 9 exercises
26 x 18.4 x 2 cm, 0.59 kg

Noncircular Gears: Design and Generation represents the extension of the modern theory of gearing applied to the design and manufacture of the main types of noncircular gears: conventional and modified elliptical gears, eccentric gears, oval gears, gears with lobes, and twisted gears. This book is enhanced by updated theoretical description of the methods of generation of noncircular gears by enveloping methods similar to those applied to the generation of circular gears. Noncircular Gears: Design and Generation also offers new developments directed to extend the application of noncircular gears for output speed variation and generation of functions. Numerous numerical examples show the application of the developed theory. This book aims to extend the application of noncircular gear drives in mechanisms and industry.

1. Introduction to theory of gearing, design, and generation of noncircular gears
2. Centrodes of noncircular gears
3. Evolutes and involutes
4. Elliptical gears and gear drives
5. Generation of planar and helical elliptical gears
6. Design of gear drives formed by eccentric circular gear and conjugated noncircular gear
7. Design of internal noncircular gears
8. Application for design of planetary gear train with noncircular and circular gears
9. Transformation of rotation into translation with variation of gear ratio
10. Tandem design of mechanisms for function generation and output speed variation
11. Additional numerical problems.

Subject Areas: Engines & power transmission [TGBN], Mechanical engineering [TGB], Mechanical engineering & materials [TG]
