Microwave Devices, Circuits and Their Interaction

Charles A. Lee (Author), G. Conrad Dalman (Author)

9780471552161, Wiley

Hardback, published 26 April 1994

384 pages
24 x 16 x 2.5 cm, 0.709 kg

Divided into three main segments with emphasis on both small and large signal interaction effects as well as linear and nonlinear characteristics. Part One deals with microwave circuits, their parameters and methods of characterizing them. Part Two describes microwave solid-state devices that are usable for amplifiers and oscillators. Lastly, it delves into some of the interactions which occur when solid-state instruments are embedded into microwave circuits. Features a significant amount of worked examples.

MICROWAVE CIRCUITS.

Review of Transmission Lines, Waveguides, and Smith ChartAnalysis.

Linear Microwave Network Parameters.

Waveguide and Transmission Line Parameters.

Transmission Lines as Resonators and Circuit Elements.

Microwave Networks and Components.

MICROWAVE SOLID-STATE DEVICES.

Solid-State Theory: Special Topics.

Schottky Barrier Diodes.

Microwave Transistors.

IMPATT Diodes.

Gunn Diodes.

DEVICE-CIRCUIT INTERACTION.

Transistor Amplifier Properties.

Two-Terminal Negative-Resistance Amplifiers.

Oscillators.

Noise.

Appendix.

Index.

Subject Areas: Electronics & communications engineering [TJ]
