LCP for Microwave Packages and Modules

A comprehensive overview of RF microelectronic design using Liquid Crystal Polymer (LCP) at package, component and system levels.

Anh-Vu H. Pham (Author), Morgan J. Chen (Author), Kunia Aihara (Author)

9781107003781, Cambridge University Press

Hardback, published 21 June 2012

266 pages, 227 b/w illus. 24 tables
25.3 x 17.6 x 1.6 cm, 0.68 kg

'These foremost experts have created a compendium on microwave and millimeter-wave applications of LCP in packaging and modules that is clear and comprehensive, starting with materials science and theory, going through wide-ranging and current practical applications, and even covering all of the practical reliability aspects. Moreover, they have revealed in detail a host of design tricks (such as defected grounds) and advanced circuitry (such as a folded Marchand balun with a broadband even-mode matching network) that can enhance the designer's arsenal in general. We have here a valuable text for microwave designers at all levels.' Ed Stoneham, Stoneham Innovations

A comprehensive overview of electrical design using Liquid Crystal Polymer (LCP), giving you everything you need to know to get up-to-speed on the subject. This text describes successful design and development techniques for high-performance microwave and millimeter-wave packages and modules in an organic platform. These were specifically developed to make the most of LCP's inert, hermetic, low-cost, high-frequency (DC to 110+ GHz) properties. First-hand accounts show you how to avoid various pitfalls during design and development. You'll get extensive electrical design details in areas of broadband circuit design for low-loss interconnects, couplers, splitters/combiners, baluns, phase shifters, time-delay units (TDU), power amplifier (PA) modules, receiver modules, phased-array antennas, flexible electronics, surface mounted packages, Microelectromechanical Systems (MEMS) and reliability. Ideal for engineers in the fields of RF, microwave, signal integrity, advanced packaging, material science, optical and biomedical engineering.

1. Introduction
2. Characteristics of liquid crystal polymer (LCP) Morgan J. Chen, Kunia Aihara, Cheng Chen and Anh-Vu H. Pham
3. Fabrication techniques for processing LCP laminates
4. LCP for wafer level chip scale MEMS
5. LCP for surface mount interconnects, packages, and modules
6. LCP for passive components Hai Ta, Morgan J. Chen, Kunia Aihara, Andy C. Chen, Jia-Chi Samual Chieh and Anh-Vu H. Pham
7. LCP for system design Morgan J. Chen, Kunia Aihara, Andy C. Chen, Jia-Chi Samual Chieh and Anh-Vu H. Pham
8. LCP reliability.

Subject Areas: Television technology [TJKV], Telephone technology [TJKT], Satellite communication [TJKS], Communications engineering / telecommunications [TJK], Electronics engineering [TJF], Electronics & communications engineering [TJ]
