AVR RISC Microcontroller Handbook

Claus Kuhnel (Author)

9780750699631

Paperback, published 2 October 1998

312 pages
25.2 x 19.5 x 2 cm, 0.45 kg

The AVR RISC Microcontroller Handbook is a comprehensive guide to designing with Atmel's new controller family, which is designed to offer high speed and low power consumption at a lower cost. The main text is divided into three sections: hardware, which covers all internal peripherals; software, which covers programming and the instruction set; and tools, which explains using Atmel's Assembler and Simulator (available on the Web) as well as IAR's C compiler.

Some Basics: Architecture, Important Terms, NumbersHardware Resources of the AVR Microcontroller: Architectural Overview, Arithmetic Logic Unit (ALU), Program and Data Memories, Peripherals, Reset and Interrupt System, ClockHandling the Hardware Resources: Memory Addressing Modes, Instruction Set, Reset and Interrupt Handling, Watchdog Handling, Stack, Program Constructs, Defensive ProgrammingDevelopment Tools: Atmel AVR Assembler and Simulator, Atmel AVR Studio, IAR Embedded Workbench EWA90, AVR Pascal from E-LAB Computers, AVR BASIC from Silicon Studio, Programmer & Evaluation BoardsExample Programs: Example Programs in AVR Assembler, Example Program in C, Example Programs in AVR BASICAppendix: Part Numbering Systems, Pin Configurations, Schematics of SIMMSTICK (TM) Modules, Register and Bit Definitions, Some Fundamentals to RS-232, Some Fundamentals to RS-422 and RS-485, 8-bit Intel Hex File Format, Decimal-to-Hex-to-ASCII Converter, Overview of Atmel's Application Notes & Software, Literature, Contacts

Subject Areas: Microprocessors [TJFD1]
