Advanced Computer-Aided Fixture Design

First book to guide engineers in the use of CAD for design of machining Fixtures as integrated system components of overall machining and manufacturing processes

Yiming (Kevin) Rong (Author), Samuel Huang (Author)

9780125947510

Hardback, published 14 June 2005

424 pages, Approx. 250 illustrations
22.9 x 15.1 x 2.7 cm, 0.77 kg

Fixtures--the component or assembly that holds a part undergoing machining--must be designed to fit the shape of that part and the type of machining being done. This book discusses the fundamentals of Computer-Aided Fixture Design (CAFD) techniques and covers fixture planning, fixture design (both modular and dedicated fixtures), fixture design verifications, and the overall integration with CAD/CAM. The book shows how CAFD may lead to a significant reduction of product and process development time and production cost, and how CAFD can increase quality assurance through simulation and science-based technical specification and cost estimation in business quoting, especially in current supplier-based manufacturing. It also provides case study examples.

1. Background2. Machining Setup Planning3. Fixture Planning4. Fixture Configuration Design5. Fixture Design Verification

Subject Areas: Mechanical engineering [TGB]
