Active Filter Cookbook

DON LANCASTER (Author)

9780750629867, Elsevier Science

Paperback, published 5 September 1996

240 pages
21.6 x 13.8 x 1.6 cm, 0.304 kg

This Don Lancaster classic is by far the best-selling active filter book of all time. It gives you everything you need to know to build active lowpass, bandpass, and highpass filters.
An active filter needs no inductors. Instead, op amps, resistors, and capacitors are used for better results. Advantages include lower cost, easy tuning, simple design, and modularity. Lancaster's Active Filter Cookbook includes practical elements such as working circuits, ready-to-use design tables, tuning, and real-world applications, making it easy to use and apply. You'll find both instant design and the mathematics behind coverage. Microcomputer pioneer Don Lancaster is the author of 34 books, 2 videos and countless articles and columns in technical magazines. He also heads Synergetics, an Arizona-based design and consulting firm.

Some basics
The operational amplifier
First- and second-order networks
Low-pass and high-pass filter responses
Bandpass filter response
Low-pass filter circuits
Bandpass filter circuits
High-pass filter circuits
Tuning, voltage control and elliptical filters
Applications
References
Index.

Subject Areas: Circuits & components [TJFC]
